86 & 96 Series – Spring Loaded Flange Socket Ball Transfer Units

96 Series 96 Series 96 Series 96 Series
96 Series
Switch measurements:
Part Supports Load (lb)Supports Load (kg) Deflection (″)Deflection (mm) Load at max deflection (lb)Load at max deflection (kg) BALL ⌀ ″BALL ⌀ (MM) A B C D E F$ fromFile icon FilesAdd to Cart
8601 26 12 0.130 3.3 101 46 1/2" 12.7 1.000 25.4 1.000 25.4 0.197 5 1.969 50 1.417 36 2 x 0.203 2 x 5.1 $91,54PDF Step
9620 200 91 0.189 4.8 415 188 1" 25.4 2.000 50.8 2.185 55.5 0.236 6 3.150 80 2.559 65 3 x 0.234 3 x 6.1 $251,09PDF Step
9630 500 227 0.094 2.4 809 367 1" 25.4 2.500 63.5 2.374 60.3 0.236 6 3.937 100 3.150 80 3 x 0.318 3 x 8.1 $261,62PDF Step
9640 992 450 0.394 10 2117 960 1 1/2" 38.1 2.752 69.9 4.500 114.3 0.394 10 4.528 115 3.622 92 3 x 0.398 3 x 10.1 $695,51PDF Step
9650 2200 1000 0.240 6.1 4410 2000 2" 50.8 4.724 120 5.469 138.9 0.472 12 6.496 165 5.512 140 3 x 0.398 3 x 10.1 $1.784,83PDF Step
8601A 26 12 0.130 3.3 101 46 1/2" 12.7 1.000 25.4 1.000 25.4 0.197 5 1.969 50 1.417 36 2 x 0.203 2 x 5.1 $104,14PDF Step
9620A 200 91 0.189 4.8 415 188 1" 25.4 2.000 50.8 2.185 55.5 0.236 6 3.150 80 2.559 65 3 x 0.234 3 x 6.1 $277,10PDF Step
9630A 500 227 0.094 2.4 809 367 1" 25.4 2.500 63.5 2.374 60.3 0.236 6 3.937 100 3.150 80 3 x 0.318 3 x 8.1 $291,04PDF Step
9640A 992 450 0.394 10 2117 960 1 1/2" 38.1 2.752 69.9 4.500 114.3 0.394 10 4.528 115 3.622 92 3 x 0.398 3 x 10.1 $795,68PDF Step
9650A 2200 1000 0.240 6.1 4410 2000 2" 50.8 4.724 120 5.469 138.9 0.472 12 6.496 165 5.512 140 3 x 0.398 3 x 10.1 $1.938,33PDF Step
8601Z 26 12 0.130 3.3 101 46 1/2" 12.7 1.000 25.4 1.000 25.4 0.197 5 1.969 50 1.417 36 2 x 0.203 2 x 5.1 $0,00
9620Z 200 91 0.189 4.8 415 188 1" 25.4 2.000 50.8 2.185 55.5 0.236 6 3.150 80 2.559 65 3 x 0.234 3 x 6.1 $377,77PDF Step
9630Z 500 227 0.094 2.4 809 367 1" 25.4 2.500 63.5 2.374 60.3 0.236 6 3.937 100 3.150 80 3 x 0.318 3 x 8.1 $435,87PDF Step
9640Z 992 450 0.394 10 2117 960 1 1/2" 38.1 2.752 69.9 4.500 114.3 0.394 10 4.528 115 3.622 92 3 x 0.398 3 x 10.1 $970,35PDF Step
9650Z 2200 1000 0.240 6.1 4410 2000 2" 50.8 4.724 120 5.469 138.9 0.472 12 6.496 165 5.512 140 3 x 0.398 3 x 10.1 $2.172,33PDF Step
8601SS 26 12 0.130 3.3 101 46 1/2" 12.7 1.000 25.4 1.000 25.4 0.197 5 1.969 50 1.417 36 2 x 0.203 2 x 5.1 $255,45PDF Step
9620SS 200 91 0.189 4.8 415 188 1" 25.4 2.000 50.8 2.185 55.5 0.236 6 3.150 80 2.559 65 3 x 0.234 3 x 6.1 $1.022,49PDF Step
9630SS 500 227 0.094 2.4 809 367 1" 25.4 2.500 63.5 2.374 60.3 0.236 6 3.937 100 3.150 80 3 x 0.318 3 x 8.1 $934,52PDF Step
9640SS 992 450 0.394 10 2117 960 1 1/2" 38.1 2.752 69.9 4.500 114.3 0.394 10 4.528 115 3.622 92 3 x 0.398 3 x 10.1 $2.599,10PDF Step
9650SS 2200 1000 0.240 6.1 4410 2000 2" 50.8 4.724 120 5.469 138.9 0.472 12 6.496 165 5.512 140 3 x 0.398 3 x 10.1 -PDF Step

Omnitrack Heavy Duty spring loaded units are ideal where uneven track conditions or shock loading occurs. Internal springs offer full retraction of the ball within the housing. We can tailor spring pre-loads, deflections & characteristics to your requirements. Consider alternative material upgrade options to withstand severe operating environments.

Omnitrack 96 series spring loaded ball transfer units are pre-stressed for omnidirectional & accurate positioning. As these units are from our ‘heavy duty’ range they offer the lowest coefficient of friction & smoothest performance available.

When incorporating Omnitrack 96 series units into heavy press tooling or dies, the tooling can be precisely positioned & then clamped. The additional force will cause the disc springs to deflect whilst clamped, yet once unclamped, raise the tooling ready to be maneuvered away with ease & accuracy.

Material upgrade options are shown below – order by adding the suffix to the part number required, for example, 9620 ‘A’ which includes stainless steel balls & improved resistance to high temperatures.

Spring mechanism parts remain carbon spring steel irrespective of material upgrades – consult us is other materials are required.

  • Maximum shock protection – Ball retracts fully within housing.
  • Ideal where load balancing or unequal track/load conditions exist.
  • Exceptional shock & high/low temperature resistance.
  • Maximum load capacity at any angle of orientation.
  • Robust integral mounting flange complete with 2 or 3 fixing holes.

Discover the rest of our ball transfer unit range.

Not found what you need? Call us now.

Maximum load ratingMaximum load rating unaffected at any orientation
Low FrictionLow Friction
1 : 0,0059000 Series only
SpeedSpeed
2m/sec
TemperatureTemperature
-50/+160ºC
High Shock ResistenceHigh Shock Resistence
Uneven Loads

Uneven Loads

User ServiceableUser Serviceable9000 Series only

Service Kits

Factory reconditioning service for spring loaded & custom units as these may require special tooling for safe disassembly.

service kit diagram heavy duty transfer ball diagram

Tolerance Rings

  • Compensate for irregularities in bore & diameter.
  • Ideal where only single-sided access of mounting surface is reachable.
pneumatic and wheels tolerance ring

Heavy Duty Part A BORE Ø MIN - MAX B$ fromFile icon FilesAdd to Cart
TR20 0.787 20 0.858 - 0.868 21.80 - 22.05 0.472 12 $2,17
TR45 1.772 45 1.843 - 1.850 46.80 - 47.00 0.591 15 $2,77
TR50 1.969 50 2.043 - 2.051 51.90 - 52.10 0.591 15 $4,98
TR60 2.362 60 2.445 - 2.453 62.10 - 62.30 0.787 20 $4,98
TR100 3.937 100 4.085 - 4.096 103.75 - 104.05 0.787 20 $4,44
